WELL 4″ Submersible Pumps
Compact 4-inch borehole pump series for irrigation and general water transfer. Supplied by Elmekkawy For Import and Export & Commercial Agencies with model selection based on duty point.
BrandWELL
Category4″ Submersible Pumps
Max. CapacityUp to 24 m³/h
Max. Motor PowerUp to 7.5 kW
Max. Water Temp.35 °C
Connection1¼”, 1½”, 2″ (NEMA flange)
4″ Borehole
Irrigation
Water Transfer
Up to 24 m³/h
Up to 7.5 kW
Company: Elmekkawy For Import and Export & Commercial Agencies
Brand: WELL
Bore Size: 4″
Brand: WELL
Bore Size: 4″
Key Features
- Long life & high efficiency.
- High durability and easy installation.
- Easy service operation.
- Water lubricated rubber bearing.
- Built-in check valve to prevent back flow.
- Suitable connection in NEMA standards.
Applications
- Pressurized water supply from borehole wells.
- Water supply for agriculture.
- Industrial applications.
- Pressurizing.
Selection Checklist
- Required flow rate (m³/h)
- Total head (m) + pipe diameter
- Power supply (phase / voltage / Hz)
- Well diameter + installation depth
- Sand content (if known)
- Cable length + control panel (if needed)
Get the right stages and motor
Send Flow + Head and we will recommend the correct pump configuration and matching 4″ motor, with full accessories package.
Catalogue & Downloads
Download the full catalogue for complete performance curves, dimensions, and full 50/60 Hz options.
Note: Data below is a quick overview. Refer to the PDF catalogue for the most detailed specifications and curves.
Technical Features (Overview)
| Item | Value |
|---|---|
| Max. capacity | 24 m³/h |
| Max. motor power | 7.5 kW |
| Max. water temperature | 35 °C |
| Max. pump diameter | 98 mm |
| Max. allowable sand content | 50 g/m³ |
| Discharge connection | 1¼”, 1½”, 2″ |
| Motor compatibility | NEMA standard flange connection |
Parts & Materials (Typical)
| No | Part Name | Material |
|---|---|---|
| 1 | Discharge Head | Casted Stainless Steel (AISI 304) |
| 2 | Valve Disc | Stainless Steel (AISI 304) |
| 3 | Valve Seat Retainer | Stainless Steel (AISI 304) |
| 4 | Valve Seat | Stainless Steel (AISI 304) |
| 5 | Valve Locking Ring | Stainless Steel (AISI 304) |
| 6 | Adapter Ring | Noryl |
| 7 | Bushing | Noryl |
| 8 | Bearing Spacer | Polyurethane |
| 9 | Valve Housing | Noryl |
| 10 | Diffuser | PC, 20% Glass Fiber Reinforced |
| 11 | Impeller | Noryl |
| 12 | Diffuser Casing | Stainless Steel (AISI 304) |
| 13 | Shim | Stainless Steel (AISI 304) |
| 14 | Suction Case | Stainless Steel (AISI 304) |
| 15 | Strainer | Stainless Steel (AISI 304) |
| 16 | O-ring | Rubber |
| 17 | Coupling | Stainless Steel (AISI 316) |
| 18 | Shaft | Stainless Steel (AISI 420) |
| 19 | Washer | Stainless Steel (AISI 304) |
| 20 | Shim | Stainless Steel (AISI 304) |
| 21 | Pump Casing | Stainless Steel (AISI 304) |
| 22 | Cable Guard | Stainless Steel (AISI 304) |
FAQ
What is a 4″ submersible pump used for?
It’s used for pumping clean water from boreholes for irrigation, pressurizing, farms, and general water transfer.
How do I choose the correct VSP model?
Send required flow (m³/h) + total head (m), power supply (phase/voltage/Hz), well details, and we’ll recommend the suitable stages and motor match.
Do you supply the full set?
Yes — pump, matching motor, cable, control panel, and key accessories can be supplied as a complete package.
Where can I download the catalogue?
Use the catalogue buttons above (50Hz/60Hz), and contact us for model recommendation.
